Gradled Mini: Modular Discrete LED Display

A prototype low-cost, tileable, single-color LED matrix with low power consumption and scalable to large displays

Similar projects worth following
83 views
0 followers
Read the full article on my website, complete with project specs, schematics, PCB design, firmware design, testing, and other useful thoughts!

https://nathanpetersen.com/2018/11/11/gradled-mini-prototype-modular-discrete-led-display/

gradled-mini-design.pdf

Complete schematics and PCB design for project. Designed in Eagle.

Adobe Portable Document Format - 618.14 kB - 11/12/2018 at 03:30

Preview
Download

  • 1 × EFM32TG110F32 Electronic Components / Misc. Electronic Components
  • 1 × CP2102N USB-UART
  • 1 × STP08DP05 Interface and IO ICs / Display Interface
  • 1 × HCF4094 Logic ICs / Flip-Flops, Latches, Registers
