Amazon Echo Show 10 3rd gen Teardown


Similar projects worth following

  • 1 × TCS3400 Color Light-to-Digital Converter. Red, Green, Blue, Clear and IR light sensing
  • 1 × NVT2010BS Interface and IO ICs / Logic Level Translators
  • 1 × DRV8323 6 to 60-V Three-Phase Smart Gate Driver

View project log

Enjoy this project?



teraz wrote 09/08/2021 at 17:41 point

1. is possible create energy / power from this alternator? for example put it to bicycle

2. is possible put screen to other enclosure and add keyboard and create a linux raspberry mobile device?

  Are you sure? yes | no

Darran Edmundson wrote 04/14/2021 at 20:22 point

That LoRa chip in the second-to-last image is there for Amazon Sidewalk I guess. Thankfully not enough bandwidth to broadcast your camera feed or audio. Is It true that Sidewalk is enabled by default?

  Are you sure? yes | no

wooghee wrote 04/14/2021 at 19:00 point

i am surprised by the quality of the hardware and the general engineering effort that went into this product, however the data extracted by those home spies is apparently valuable enough to justify the expense.

  Are you sure? yes | no

Gregor wrote 04/10/2021 at 13:21 point

Very nice teardown, thanks for the thorough work!

  Are you sure? yes | no

Davide Ercolano wrote 04/10/2021 at 08:31 point

Hello! Thanks for this really interesting teardown! Since is unreadable from the picture, could you please indicate which amplifier chip is that?

  Are you sure? yes | no

GekkePrutser wrote 04/09/2021 at 04:36 point

Huh?? What are all these coils for??

Is that some kind of subwoofer or something?

Edit: Ahhh I see it follows you around. I wasn't familiar with this model. Still seems like a very expensive way of doing that though. I'd probably go for a simple stepper motor and a positional sensor? This'll be quieter and more responsive but it'll cost a lot of copper and coil drivers I bet.

  Are you sure? yes | no

Daren Schwenke wrote 04/09/2021 at 18:26 point

I imagine being totally silent while moving was a very high priority as video conferencing seems like a good use case.  Drive that BLDC with a sine drive with pwm above range of human hearing and you are good to go.

  Are you sure? yes | no

Xasin wrote 04/09/2021 at 22:25 point

Have you ever seen how silent a regular stepper can be with a Trinamic driver?
Choosing the right parameters, using a lower current to drive the motor, and it would absolutely be whisper quiet.

So yeah, that amount of coils is... Why?

At least seeing the amount of basically wasted electronics just to deliver a slightly more fancy user experience makes me much more comfortable with putting a little extra effort into some of my things ^^'

  Are you sure? yes | no

Davide Ercolano wrote 04/10/2021 at 08:33 point

Also, I think they evaluated a lot of alternative in the R&D process, probably this solution is the best option to have smooth and silent movements

  Are you sure? yes | no

Bharbour wrote 04/09/2021 at 23:33 point

There is probably only 3 separate sets of coil drivers. This would be consistent with the way a brushless DC motor is built.

  Are you sure? yes | no

3gfisch wrote 04/14/2021 at 22:21 point

This is more or less a stepper motor, a BLDC motor build specific for this use case, if you produce enough it could be even cheaper, since you don’t pay an other manufactures profit and have no not needed case and bearing from a standard motor.. in general this Design is beautifully, a real direkt drive, no gears no belts -> no sound no wearing -> perfect Engineering choice if its the cheapest solution i don’t know. (open up a stepper or BLDC motor and you will also find many coils...)

  Are you sure? yes | no

StefanBruens wrote 04/25/2021 at 19:09 point

Not "more or less", but just a custom BLDC, with 27 slots and 30 poles. It is driven by 3 pairs of MOSFETs, using the DRV8323 gate driver, controlled with an STM32F4. See the UFO-shaped PCB.

The comparatively high slot/pole count (for a BLDC) makes it a good choice for slow and smooth movement.

Compared with a conventional 2-phase bipolar stepper motor, a BLDC has a much higher power density at a significant lower weight. The huge size allows to use a central bearing carrying the weight of the rotating part.

  Are you sure? yes | no
