Dave's 1-Bit Full Adder

A BreadBoard Friendly 1-Bit Full Adder Design

Dave's Dev LabDave's Dev Lab
Following Follow project
Liked Like project

Become a Hackaday.io member

Not a member? You should Sign Up.

Already have an account? Log In.

Sign up with Github
Sign up with Twitter OR
Forgot your password?

Just one more thing

To make the experience fit your profile, pick a username and tell us what interests you.

Pick an awesome username
hackaday.io/
Your profile's URL: hackaday.io/username. Max 25 alphanumeric characters.
Pick a few interests
Projects that share your interests
People that share your interests

We found and based on your interests.

Choose more interests.

OK, I'm done! Skip
Join this project
Similar projects worth following
1.3k views
2 comments
14 followers
20 likes
  • Description
  • Details
  • Files 3
    • View all
  • Components 6
    • View all
  • Logs 1
    • View all
  • Instructions 0
  • Discussion 2
View Gallery
1.3k
2
14
20

Team (1)

  • Dave's Dev LabDave's Dev Lab

Join this project's team
  • Purchase on Tindie
completed project
Digital logic computer basics Digital Design alu CPU

Related lists

Awesome Projects on Tindie

Hackaday.io projects you can buy in the Tindie maker marketplace

Cool Stuff

A list of cool electronic stuff.

Digital Design Prototyping Tools

A list of tools and projects for Digital Design Prototyping

This project is submitted for

  • Hackaday.com Tip Line
  • The Return of the Square Inch Project

This project was created on 05/18/2017 and last updated 2 years ago.

Description

This project is to create a small breadboard friendly 1-bit full adder. These can be chained together to create a 4-bit or 8-bit adder, as well as combined with other logic such as "Dave's Boolean Bits" to create a simple arithmetic-logic unit (ALU). The PCB is 0.9" x 1.0" for a total of 0.9 square inches.

Files

1-bit_full-adder-gerbers.zip

Gerber Manufacturing Files - This work is licensed under a Creative Commons Attribution-NonCommercial 4.0 International License. CC-BY-NC 4.0. Copyright (C) 2018, David Anders. All Rights Reserved.

Zip Archive - 27.66 kB - 09/06/2018 at 20:55

Download

ddl-1bit_full_adder-design.zip

Eagle CAD Design Files - This work is licensed under a Creative Commons Attribution-NonCommercial 4.0 International License. CC-BY-NC 4.0. Copyright (C) 2018, David Anders. All Rights Reserved.

Zip Archive - 51.21 kB - 09/06/2018 at 20:55

Download

1-bit_full-adder.pdf

PDF Schematic - This work is licensed under a Creative Commons Attribution-NonCommercial 4.0 International License. CC-BY-NC 4.0. Copyright (C) 2018, David Anders. All Rights Reserved.

Adobe Portable Document Format - 16.55 kB - 09/06/2018 at 20:55

Preview
Download

Components

  • 2 × 74LVC1G86 Exclusive OR (XOR) Gate SOT23-5 Package https://www.digikey.com/products/en?keywords=296-9853-1-ND
  • 2 × 74LVC1G08 AND Gate SOT23-5 Package https://www.digikey.com/products/en?keywords=296-11601-1-ND
  • 1 × 74LVC1G32 OR Gate SOT23-5 Package https://www.digikey.com/products/en?keywords=296-9847-1-ND
  • 5 × 220 Ohm Resistor 0603 Package https://www.digikey.com/products/en?keywords=311-220GRCT-ND
  • 5 × 0.1uF Ceramic Capacitor 0603 Package https://www.digikey.com/products/en?keywords=490-1532-1-ND

View all 6 components

Project Logs
Collapse logs

  • SMD Assembly by Hand

    Dave's Dev Lab • 02/18/2018 at 23:50 • 1 comment

View project log

Enjoy this project?

Share

Discussions

Log In/Sign up to comment

Become a Hackaday.io Member

Create an account to leave a comment. Already have an account? Log In.

Sign up with Github
Sign up with Twitter OR
Dave's Dev Lab wrote 04/13/2018 at 16:39 • point

@Dr. Cockroach - hehe no worries, just another research project on the road to my 4-bit cpu design...

  Are you sure? yes | no

Dr. Cockroach wrote 04/13/2018 at 15:54 • point

Good afternoon Dave, sorry I had not noticed this project before now :-)

  Are you sure? yes | no
